| Varenummer | A043FW02 V0 |
| Mærke | AUO |
| Størrelse | 4.3 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A043FW02 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2 mm |
| overflade | Antiglare (Haze 8%), Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S1PWLED |
| signal interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Ansøgning | PND |
| 43WQW1H | SII | 4.3 | 480×272 |
| A043FW02 V0 | AUO | 4.3 | 480×272 |
| A043FW02 V8 | AUO | 4.3 | 480×272 |
| A043FW03 V2 | AUO | 4.3 | 480×272 |
| AT043TN24 V.1 | Innolux | 4.3 | 480×272 |
| HSD043I9W1-B00 | HannStar | 4.3 | 480×272 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LMS430HF27 | Samsung | 4.3 | 480×272 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| YX-CM043-QN05-56 | 4.3 | 480×272 |
| 43WVF0H | SII | 4.3 | 800×480 |
| A040FL01 V2 | AUO | 4.0 | 480×272 |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| CLAA048LA0BCW | CPT | 4.8 | 800×480 |
| DLC0700FDG-T-6 | Other | 7.0 | 800×480 |
| LB043WQ3-TD03 | LG Display | 4.3 | 480×272 |
| LMS500HF07 | Samsung | 5.0 | 480×272 |
| LQ043T1DH42 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| PA040XS1 | E Ink | 4.0 | 320×234 |
