| Varenummer | 35QVW1T |
| Mærke | SII |
| Størrelse | 3.5 |
| Ansøgning | PND |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SII |
| panel model | 35QVW1T |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 70.08×52.56 mm |
| omrids | 76.9×63.9 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S1PWLED |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| Ansøgning | PND |
| 35QVW1H | SII | 3.5 | 320×240 |
| 35QVW1T | SII | 3.5 | 320×240 |
| A035QN05 V1 | AUO | 3.5 | 320×240 |
| ACX565AKM-7 | SONY | 3.5 | 800×480 |
| COM35H3P09UTC | ORTUSTECH | 3.5 | 480×640 |
| LQ035Q1DG01 | SHARP | 3.5 | 320×240 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| PD035OX4 | E Ink | 3.5 | 320×234 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
| A050FW02 V5 | AUO | 5.0 | 480×272 |
| AT050TN43 V.1 | Innolux | 5.0 | 800×480 |
| DLC0430LZG-8 | Other | 4.3 | 480×272 |
| DLC0500HZG-8 | Other | 5.0 | 800×480 |
| HSD050IDW1-A30 | HannStar | 5.0 | 800×480 |
| HST043BOH57-40AV0 | Other | 4.3 | 480×272 |
| LMS480JC01 | Samsung | 4.8 | 1024×600 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LMS500HF13-003 | Samsung | 5.0 | 480×272 |
| LTE430WQ-F07 | Samsung | 4.3 | 480×272 |
