| Varenummer | LQ043Y1DX01 |
| Mærke | SHARP |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 900:1 |
| Farver | 65K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ043Y1DX01 3 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 56.16×93.6 mm |
| omrids | 62.46×105.9×2.3 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 65K , CIE193172% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S1PWLEDWithout Driver |
| signal interface | Parallel RGB, 45 pins |
| indgangsspænding | 3.0/2.6V (Typ.)(VCI/VDDIO) |
| Ansøgning | MPH |
| LQ043T1DG01 | SHARP | 4.3 | 480×272 |
| LQ043T1DG02 | SHARP | 4.3 | 480×272 |
| LQ043T1DG03B | SHARP | 4.3 | 480×272 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LQ043T3DG01 | SHARP | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0E | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01 | SHARP | 4.3 | 480×800 |
| LQ043Y1DX03D | SHARP | 4.3 | 480×800 |
| AMS369FG06-0 | Samsung | 3.7 | 480×800 |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| H497DAN01.0 | AUO | 5.0 | 1080×1920 |
| HVA42WV1-M00 | HYDIS | 4.2 | 480×800 |
| LH400WV3-SD04 | LG Display | 4.0 | 480×800 |
| LH550WF4-SD01 | LG Display | 5.5 | 1080×1920 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| LTM030DH60 | TOSHIBA | 3.0 | 240×427 |
| TM032PDZ13 | Tianma | 3.2 | 320×480 |
| TM055JVZG02 | Tianma | 5.5 | 720×1280 |
