| Varenummer | CM546B1-002 |
| Mærke | CSOT |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1200:1 |
| Farver | |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | CSOT |
| panel model | CM546B1-002 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.5 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 69.64×127.19 mm |
| overflade | With Polarizer |
| glas dybde | 0.15+0.15 mm |
| transmissivitet | 4.81% (Typ.)(with APCF) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | , CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Ansøgning | MPH |
