| Varenummer | LQ080Y5DG03 |
| Mærke | SHARP |
| Størrelse | 8.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 540 |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ080Y5DG03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 174×104.4 mm |
| omrids | 190×120 mm |
| overflade | |
| lysstyrke | 540 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 262K (6-bit), CIE193165% |
| responstid | |
| synsvinkel | |
| lampe type | WLED |
| signal interface | Parallel RGB (1 ch, 6-bit) |
| Ansøgning | CNS |
