| Varenummer | LQ080Y5DZ03 |
| Mærke | SHARP |
| Størrelse | 8.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 640 |
| CR | 2000:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ080Y5DZ03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 174×104.4 mm |
| omrids | 191.8×120 mm |
| overflade | Antiglare, Reflection 1.5% (Typ.) |
| lysstyrke | 640 cd/m² (Typ.) |
| kontrastforhold | 2000:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193164% |
| responstid | 15/5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6-bit), 68 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
| LQ080T3AG01 | SHARP | 8.0 | 480×234 |
| LQ080T5GG01B | SHARP | 8.0 | 480×234 |
| LQ080V3DG01 | SHARP | 8.0 | 640×480 |
| LQ080Y5CGQ2 | SHARP | 8.0 | 800×480 |
| LQ080Y5DG02 | SHARP | 8.0 | 800×480 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| LQ080Y5DR01 | SHARP | 8.0 | 800×480 |
| LQ080Y5DW03 | SHARP | 8.0 | 800×480 |
| LQ080Y5DZ03 | SHARP | 8.0 | 800×480 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| HSD070IFW1-A00 | HannStar | 7.0 | 1024×600 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LB043WQ4-TD01 | LG Display | 4.3 | 480×272 |
| LB080WV4-TD02 | LG Display | 8.0 | 800×480 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ6BW506 | SHARP | 5.8 | 400×234 |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| YX-CM043-QN05-56 | 4.3 | 480×272 |
