| Varenummer | LQ088H9DZ03 |
| Mærke | SHARP |
| Størrelse | 8.8 |
| Ansøgning | CNS |
| Løsning | 640×240 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 180:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ088H9DZ03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.8 inch |
| løsning | 640(RGB)×240 , HVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 209.28×78.48 mm |
| omrids | 231.6×103.3 mm |
| overflade | Antiglare |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 180:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit) |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/45/45 (Typ.)(CR≥15)(L/R/U/D) |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| indgangsspænding | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
| Ansøgning | CNS |
