| Varenummer | LQ5AW136R |
| Mærke | SHARP |
| Størrelse | 5.0 |
| Ansøgning | CNS |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 60:1 |
| Farver | |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | SHARP |
| panel model | LQ5AW136R |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 102.2×74.8 mm |
| omrids | 126.8×89.6×16.8 mm |
| overflade | Antiglare, Antireflection |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 60:1 (Min.) |
| vise farver | |
| responstid | 30/50 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/40/65 (Typ.)(CR≥5)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 22 pins |
| indgangsspænding | 8.0/-5V(Typ.)(VSH/VSL) |
| Ansøgning | CNS |
| A050VW02 V0 | AUO | 5.0 | 480×800 |
| CLAN050LE61 1XE | CPT | 5.0 | 540×960 |
| LQ050A5BS02 | SHARP | 5.0 | 320×234 |
| LQ050T1SX05(G) | SHARP | 5.0 | 1080×1920 |
| LQ5AW136 | SHARP | 5.0 | 320×234 |
| LQ5AW136R | SHARP | 5.0 | 320×234 |
| LQ5AW136T | SHARP | 5.0 | 320×234 |
| LTE052T-45 | Philips | 5.0 | 320×234 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| PA050XSH | E Ink | 5.0 | 320×234 |
| C058GW01 V0 | AUO | 5.8 | 400×240 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| L5S30883P00 | SANYO | 4.5 | 480×240 |
| LA058WQ1-SD01 | LG Display | 5.8 | 400×240 |
| LQ070T5DG30 | SHARP | 7.0 | |
| M101GWT9 R3 | IVO | 10.1 | 1024×600 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| YX090DKN01.0 | SEBO | 9.0 | 1280×720 |
