| Varenummer | LQ156D1JW37 |
| Mærke | Sharp |
| Størrelse | 15.6 |
| Ansøgning | Laptop |
| Løsning | 3840×2160 |
| Sammensætning | Oxide TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| mærke | Sharp |
| model | LQ156D1JW37 (SHP1491) |
| diagonal størrelse | 15.6 inch |
| type | Oxide TFT-LCD, LCM |
| pixel format | 3840(RGB)×2160 [UHD] 282PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 345.6(H)×194.4(V) mm |
| omrids dim. | 351.9(H)×208.6(V) ×5.42(D) mm |
| bezel område | - |
| behandling | Antiglare (Haze 42%), Hard coating (3H) |
| luminans | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| driftstilstand | IPS, Normally Black, Transmissive |
| støtte farve | 16.7M 100% Adobe RGB |
| lyskilde | WLED , 15K hours , With LED Driver |
| form stil | Slim (PCBA Bent, T≤3.0mm) |
| designet til | Laptop |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
