| Varenummer | LQ156T3LW02 |
| Mærke | SHARP |
| Størrelse | 15.6 |
| Ansøgning | GM |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LQ156T3LW02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 344.232×193.536 mm |
| omrids | 363.8×215.9 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 16.2M (6-bit + FRC), CIE193176% |
| responstid | |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit) |
| Ansøgning | GM |
