| Varenummer | LQ156D1JW04 |
| Mærke | SHARP |
| Størrelse | 15.6 |
| Ansøgning | NBPC |
| Løsning | 3840×2160 |
| Sammensætning | LCM |
| Lysstyrke | 330 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | SHARP |
| panel model | LQ156D1JW04 |
| paneltype | IGZO TFT-LCD , LCM |
| panelstørrelse | 15.6 inch |
| løsning | 3840(RGB)×2160 , UHD |
| visningstilstand | New Mode2, Normally Black, Transmissive |
| aktivt område | 345.6×194.4 mm |
| omrids | 367.98×218.31×3.14 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 330 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (4 Lanes), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
