| Varenummer | LS020A8DX02 |
| Mærke | SHARP |
| Størrelse | 2.0 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | SHARP |
| panel model | LS020A8DX02 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 2.0 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | Mobile ASV, Normally Black, Transflective |
| aktivt område | 39.82×29.88 mm |
| omrids | 45.8×40.2×1.9 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.)(Transmissive)20:1 (Typ.)(Reflective) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 25/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S1PWLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, 25 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | DSC |
