| Varenummer | LH430WV1-SD01 |
| Mærke | LG Display |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MDDI |
| panel mærke | LG Display |
| panel model | LH430WV1-SD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 56.16×93.6 mm |
| omrids | 60.06×102.87 mm |
| overflade | |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 40 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 5S2PWLEDWithout Driver |
| signal interface | MDDI (2 data lanes), 24 pins |
| indgangsspænding | 2.8/2.8V (Typ.)(VCC/VCI) |
| Ansøgning | MPH |
| 990000475P | TPO | 4.3 | 800×480 |
| AA043MA01 | Mitsubishi | 4.3 | 800×480 |
| DLC0430LZG-8 | Other | 4.3 | 480×272 |
| H429AL01 V0 | AUO | 4.3 | 540×960 |
| LH430WV1-SD01 | LG Display | 4.3 | 480×800 |
| LH430WV1-SD02 | LG Display | 4.3 | 480×800 |
| LH430WV3-SH02 | LG Display | 4.3 | 480×800 |
| LS043K1SX02 | SHARP | 4.3 | 720×1280 |
| TD043MTEA2 | TPO | 4.3 | 800×480 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
| ACX399CMP-7 | SONY | 2.9 | 640×360 |
| CLAF050LG41 TXX | CPT | 5.0 | 540×960 |
| DLC0283FZG-7 | Other | 2.8 | 240×320 |
| H546TAN01.0 | AUO | 5.5 | 720×1280 |
| LH530QH1-SD01 | LG Display | 5.3 | 1440×2560 |
| LS043K1SX02 | SHARP | 4.3 | 720×1280 |
| OEL9M0039-G-E | Other | 1.5 | 128×128 |
| TD028STEB1 | TPO | 2.8 | 240×320 |
| TM020GDH42 | Tianma | 2.0 | 176×220 |
| TM040YDZ01 | Tianma | 4.0 | 480×800 |
