| Varenummer | LS038Y7DX01 |
| Mærke | SHARP |
| Størrelse | 3.8 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LS038Y7DX01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 3.8 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | Normally Black, Transflective |
| aktivt område | 49.68×82.8 mm |
| omrids | 54.6×93 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.)(Transmissive)12:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit), CIE193170% |
| responstid | 40/40 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 50 pins |
| indgangsspænding | 3.85/1.8V (Typ.)(VDC/VDDIO) |
| rohs: | |
