| Varenummer | ACX450AKN-7 |
| Mærke | JDI |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | LCM |
| Lysstyrke | 485 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | JDI |
| panel model | ACX450AKN-7 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 61.884×110.016 mm |
| omrids | 64.284×118.8×1.58 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 485 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193171% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S2PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 31 pins |
| indgangsspænding | +5.0/-5.0/1.8V (Typ.)(AVDD+/AVDD-/IOVDD) |
| Ansøgning | MPH |
