| Varenummer | TM028HBHG02 |
| Mærke | Tianma |
| Størrelse | 2.8 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 210 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | TIANMA |
| panel model | TM028HBHG02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.8 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 43.2×57.6 mm |
| omrids | 50×69.2×4.4 mm |
| overflade | Clear |
| lysstyrke | 210 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193165% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1S4PWLEDWithout Driver |
| signal interface | 8/16-bit 6080/8080 parallel, 37 pins |
| indgangsspænding | (1.8/2.8)/2.8V (Typ.)(VCC/VCI) |
| Ansøgning | MPH |
