| Varenummer | LH400WV3-SD05 |
| Mærke | LG Display |
| Størrelse | 4.0 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | LG Display |
| panel model | LH400WV3-SD05 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 51.84×86.4 mm |
| omrids | 55.54×95.8 mm |
| overflade | Clear |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S8PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 30 pins |
| indgangsspænding | 1.8/2.8/2.8 (Typ.)(IOVCC/VCC/VCI) |
| Ansøgning | MPH |
| AMS395GB02 | Samsung | 4.0 | 360×640 |
| LH400WS1-SD03 | LG Display | 4.0 | 640×1136 |
| LH400WS2-SD03 | LG Display | 4.0 | 640×1136 |
| LH400WV3-SD02 | LG Display | 4.0 | 480×800 |
| LH400WV3-SD04 | LG Display | 4.0 | 480×800 |
| LH400WV3-SD05 | LG Display | 4.0 | 480×800 |
| LS040B3SX01 | SHARP | 4.0 | 640×960 |
| LS040T3SW01 | SHARP | 4.0 | 540×960 |
| LS040T8LX02 | SHARP | 4.0 | 480×854 |
| LTM04C380K | TOSHIBA | 4.0 | 640×480 |
| ACX399CMP-7 | SONY | 2.9 | 640×360 |
| BTL507212-W746L | BOE | 5.0 | 720×1280 |
| DLC0300AMG | Other | 3.0 | 240×400 |
| DLC0320DUG | Other | 3.2 | 240×320 |
| H429AL01 V0 | AUO | 4.3 | 540×960 |
| H546DAN01.2 | AUO | 5.5 | 1080×1920 |
| LH470WX6-SD01 | LG Display | 4.7 | 750×1334 |
| LS050T1SX10 | SHARP | 5.0 | 1080×1920 |
| LTP283QV-F03 | Samsung | 2.8 | 240×320 |
| TM018FDZ12 | Tianma | 1.8 | 128×160 |
