| Varenummer | LS043T1LX01A |
| Mærke | SHARP |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 540×960 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LS043T1LX01A |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 540(RGB)×960 , qHD |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 53.46×95.04 mm |
| omrids | 58.54×105.7 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | MIPI (3 data lanes), 23 pins |
| indgangsspænding | 3.1V (Typ.) |
| Ansøgning | MPH |
| DLC0430EZG-11 | Other | 4.3 | 480×272 |
| ED043CA-01D | Innolux | 4.3 | 480×272 |
| LB043WQ3-TD03 | LG Display | 4.3 | 480×272 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LMS430HF41-004 | Samsung | 4.3 | 480×272 |
| LQ043T1DH01 | SHARP | 4.3 | 480×272 |
| LR430RC9001 | Innolux | 4.3 | 480×272 |
| LS043T1LX01A | SHARP | 4.3 | 540×960 |
| TM043NDH02 | Tianma | 4.3 | 480×272 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
| AMS369FG06-0 | Samsung | 3.7 | 480×800 |
| CLAF055LA41 TXX | CPT | 5.5 | 540×960 |
| GCX141AKM-E | SONY | 3.2 | 240×400 |
| HVA42WV1-M00 | HYDIS | 4.2 | 480×800 |
| LH430WV3-SH02 | LG Display | 4.3 | 480×800 |
| LMS320HF46 | Samsung | 3.2 | 240×432 |
| LS050T1SX01 | SHARP | 5.0 | 1080×1920 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
| TX10D121VM0AAA | JDI | 4.0 | 480×800 |
