| Varenummer | LH430WV3-SH02 |
| Mærke | LG Display |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 800:1 |
| Farver | |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | LG Display |
| panel model | LH430WV3-SH02 4 Compatible model |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 56.16×93.6 mm |
| omrids | 59.16×100.85 mm |
| overflade | Without Polarizer |
| glas dybde | 0.20+0.20 mm |
| transmissivitet | 4.4% (Typ.)(with Polarizer) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | , CIE193172% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | COG Suggest HX8369-A, LG4572B, LG4573B |
| Ansøgning | MPH |
| ACX450AKN-7 | JDI | 5.0 | 1080×1920 |
| CLAF058LA31 | CPT | 5.8 | 540×960 |
| DLC0240LZG-4 | Other | 2.4 | 240×320 |
| ET0320A5DM9 | EDT | 3.2 | 240×320 |
| H020HD01 V0 | AUO | 2.0 | 176×220 |
| H430VL02 V4 | AUO | 4.3 | 480×800 |
| LH350WS1-SH02 | LG Display | 3.5 | 640×960 |
| LH550WF2-SD03 | LG Display | 5.5 | 1080×1920 |
| LQ043Y1DX01B | SHARP | 4.3 | 480×800 |
| LTM024P339 | TOSHIBA | 2.4 | 240×320 |
