| Varenummer | TX11D101VM0EAA |
| Mærke | KOE |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 850 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | HITACHI |
| panel model | TX11D101VM0EAA |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 56.16×93.6 mm |
| omrids | 59.96×101.7 mm |
| overflade | Antireflection |
| lysstyrke | 850 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S1PWLEDWithout Driver |
| signal interface | MIPI (3 data lanes), 24 pins |
| indgangsspænding | 1.8/2.8/2.8V (Typ.)(IOVCC/VCC/VCI) |
| Ansøgning | MPH |
