| Varenummer | AMS326PM01 |
| Mærke | Samsung |
| Størrelse | 3.3 |
| Ansøgning | MPH |
| Løsning | 854×480 |
| Sammensætning | OLED |
| Lysstyrke | 300 |
| CR | 10000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | TTL |
| panel mærke | SAMSUNG SMD |
| panel model | AMS326PM01 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 3.3 inch |
| løsning | 854RG(BG)×480 , FWVGA |
| aktivt område | 72.16×40.56 mm |
| omrids | 80.56×47.36×0.86 mm |
| overflade | Glare (Haze 0%), Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE1931106% |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | Built-in D53E6EA8805 |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 61 pins |
| indgangsspænding | 1.8/3.0/3.0V (Typ.)(VCCIO1/VCCIO2/VCI) |
| Ansøgning | MPH |
