| Varenummer | TM050JVZG28 |
| Mærke | Tianma |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | Assembly |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | TIANMA |
| panel model | TM050JVZG28 |
| paneltype | a-Si TFT-LCD , Assembly |
| panelstørrelse | 5.0 inch |
| løsning | 720(RGB)×1280 , WXGA |
| aktivt område | 62.9×110.4 mm |
| omrids | 71.1×132.85 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| signal interface | MIPI (4 data lanes), 31 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(IOVCC/VCI) |
| Ansøgning | MPH |
