| Varenummer | TM047XDZP02 |
| Mærke | Tianma |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 540×960 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | TIANMA |
| panel model | TM047XDZP02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.7 inch |
| løsning | 540(RGB)×960 , qHD |
| visningstilstand | SFT, Normally Black, Transmissive |
| aktivt område | 58.32×103.68 mm |
| omrids | 62.72×113.53×1.78 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S2PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 24 pins |
| indgangsspænding | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
