| Varenummer | LTM07C757 |
| Mærke | TOSHIBA |
| Størrelse | 7.7 |
| Ansøgning | |
| Løsning | 400×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 250:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | TOSHIBA |
| panel model | LTM07C757 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.7 inch |
| løsning | 400(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 169.2×98.982 mm |
| omrids | 186.85×119.3 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 70/40 (Max.)(Tr/Td) |
| synsvinkel | 55/55/30/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
