| Varenummer | LTM184HL01 |
| Mærke | Samsung |
| Størrelse | 18.4 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1000:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM184HL01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.4 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 408.96×230.04 mm |
| omrids | 443.4×266.5×4.3 mm |
| overflade | Antiglare (Haze 1%), Antireflection |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193172% |
| responstid | 16 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 12S6PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LTM181E3-P01 | Samsung | 18.1 | 1280×1024 |
| LTM181E4-L01 | Samsung | 18.1 | 1280×1024 |
| LTM184HL01 | Samsung | 18.4 | 1920×1080 |
| LTM185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT02 | Samsung | 18.5 | 1366×768 |
| LTM185AT04 | Samsung | 18.5 | 1366×768 |
| LTM185AT05 | Samsung | 18.5 | 1366×768 |
| LTN184KT01-F01 | Samsung | 18.4 | 1680×945 |
| LTN184KT01-J01 | Samsung | 18.4 | 1680×945 |
| LTN184KT02-T01 | Samsung | 18.4 | 1680×945 |
| CLAA260WU09M | CPT | 25.5 | 1920×1200 |
| LM170E03-TLL1 | LG Display | 17.0 | 1280×1024 |
| LM190WX1-TLL1 | LG Display | 19.0 | 1440×900 |
| LM200WD3-TLF2 | LG Display | 20.0 | 1600×900 |
| LM215DB-T02 | PANDA | 21.5 | 1920×1080 |
| LQ315D1JG03 | SHARP | 31.5 | 3840×2160 |
| M190EG02 V4 | AUO | 19.0 | 1280×1024 |
| MT190AW02 V.0 | Innolux | 19.0 | 1440×900 |
| TD170WGCB2 | TPO | 17.0 | 1280×1024 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
