| Varenummer | VVX16T010J00 |
| Mærke | Panasonic |
| Størrelse | 15.5 |
| Ansøgning | NBPC |
| Løsning | 2880×1620 |
| Sammensætning | LCM |
| Lysstyrke | 355 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | Panasonic |
| panel model | VVX16T010J00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.5 inch |
| løsning | 2880(RGB)×1620 |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 343.872×193.428 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare |
| lysstyrke | 355 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 26 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S8PWLEDEmbedded (LED Driver) |
| signal interface | eDP (4 Lanes), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| VVX16T010J00 | Panasonic | 15.5 | 2880×1620 |
| VVX16T020G00 | Panasonic | 15.5 | 2880×1620 |
| B154SW01 V0 | AUO | 15.4 | 1680×1050 |
| B156HW01 V3 | AUO | 15.6 | 1920×1080 |
| LP140WH8-TPH1 | LG Display | 14.0 | 1366×768 |
| LP141WX1-TLE1 | LG Display | 14.1 | 1280×800 |
| LP156WF4-SLBA | LG Display | 15.6 | 1920×1080 |
| LT141DEQ8B00 | TOSHIBA | 14.1 | 1440×900 |
| LTN141AT08-001 | Samsung | 14.1 | 1280×800 |
| N156BGE-L21 | Innolux | 15.6 | 1366×768 |
| N156BGE-L31 | Innolux | 15.6 | 1366×768 |
| N156O6-L01 | Innolux | 15.6 | 1600×900 |
