| Varenummer | LTN160AT03-002 |
| Mærke | Samsung |
| Størrelse | 16.0 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN160AT03-002 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 16.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 353.45×198.72 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | LVDS (1 ch, 6-bit) |
| Ansøgning | NBPC |
| LTN160AT01-A02 | Samsung | 16.0 | 1366×768 |
| LTN160AT01-A05 | Samsung | 16.0 | 1366×768 |
| LTN160AT01-W01 | Samsung | 16.0 | 1366×768 |
| LTN160AT02-002 | Samsung | 16.0 | 1366×768 |
| LTN160AT02-H02 | Samsung | 16.0 | 1366×768 |
| LTN160AT03-001 | Samsung | 16.0 | 1366×768 |
| LTN160AT03-002 | Samsung | 16.0 | 1366×768 |
| LTN160AT04-N01 | Samsung | 16.0 | 1366×768 |
| LTN160AT05-001 | Samsung | 16.0 | 1366×768 |
| LTN160AT06-B01 | Samsung | 16.0 | 1366×768 |
| B154EW08 V1 | AUO | 15.4 | 1280×800 |
| LP154WE3-TLB1 | LG Display | 15.4 | 1680×1050 |
| LP156WH2-TLA1 | LG Display | 15.6 | 1366×768 |
| LQ108M1JW02 | SHARP | 10.8 | 1920×1080 |
| LQ133K1LA04 | SHARP | 13.3 | 1280×800 |
| LT133EE09C00 | TOSHIBA | 13.3 | 1366×768 |
| LT133EE10300 | TOSHIBA | 13.3 | 1366×768 |
| LTN140KT04-201 | Samsung | 14.0 | 1600×900 |
| LTN156AT36-D01 | Samsung | 15.6 | 1366×768 |
| N116HSE-EA2 | Innolux | 11.6 | 1920×1080 |
