| Varenummer | LTV350QV-F04 |
| Mærke | Samsung |
| Størrelse | 3.5 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SAMSUNG |
| panel model | LTV350QV-F04 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, TMR |
| aktivt område | 70.08×52.56 mm |
| omrids | 76.9×63.9×3.35 mm |
| overflade | |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 300 : 1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 54 pins |
| indgangsspænding | 3.3/4.9/18.0/-10.0V (Typ.)(VCC/DDVDH/VGH/VGL) |
| Ansøgning | DSC |
| 990000553 | TPO | 3.5 | 320×240 |
| A035QN05 V0 | AUO | 3.5 | 320×240 |
| EL160.80.50 | Lumineq | 3.5 | 160×80 |
| GPM782A0 | Giantplus | 3.5 | 320×240 |
| LTV350QV-F02 | Samsung | 3.5 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| LTV350QV-F05 | Samsung | 3.5 | 320×240 |
| LTV350QV-F07 | Samsung | 3.5 | 320×240 |
| LTV350QV-F09 | Samsung | 3.5 | 320×240 |
| LTV350QV-F0E | Samsung | 3.5 | 320×240 |
| 990000738A | Innolux | 3.5 | 320×240 |
| A024CN03 V2 | AUO | 2.4 | 480×234 |
| ACX318ELN | SONY | 1.5 | 490×240(dot) |
| CLAA030HA22DE | CPT | 3.0 | 960×480(dot) |
| DLC0350FVG-5 | Other | 3.5 | 320×240 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| LQ035Q1DH01 | SHARP | 3.5 | 320×240 |
| PA025XSB | E Ink | 2.5 | 480×234 |
| PD035OX4 | E Ink | 3.5 | 320×234 |
| TM035KBH02 | Tianma | 3.5 | 320×240 |
