| Varenummer | LTV350QV-F09 |
| Mærke | Samsung |
| Størrelse | 3.5 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SAMSUNG |
| panel model | LTV350QV-F09 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, TMR |
| aktivt område | 70.08×52.56 mm |
| omrids | 76.9×63.9×4.45 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 300 : 1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 60 pins |
| indgangsspænding | 3.3/4.9/18.0/-10.0V (Typ.)(VCC/DDVDH/VGH/VGL) |
| Ansøgning | DSC |
| GCX123AKQ-E | JDI | 3.5 | 240×320 |
| LQ035Q3DG02A | SHARP | 3.5 | 320×240 |
| LTV350QV-F02 | Samsung | 3.5 | 320×240 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| LTV350QV-F05 | Samsung | 3.5 | 320×240 |
| LTV350QV-F07 | Samsung | 3.5 | 320×240 |
| LTV350QV-F09 | Samsung | 3.5 | 320×240 |
| LTV350QV-F0E | Samsung | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| TM035NDH04 | Tianma | 3.5 | 272×480 |
| A015AN03 V0 | AUO | 1.46 | 280×220 |
| A015AN04 V6 | AUO | 1.5 | 280×220 |
| A024CN02 VL | AUO | 2.4 | 480×234 |
| A027DN04 V3 | AUO | 2.7 | 320×240 |
| A030DN04 V0 | AUO | 3.0 | 320×240 |
| LQ035Q1DH01 | SHARP | 3.5 | 320×240 |
| PA025XSF | E Ink | 2.5 | 480×234 |
| PT035TN23 V.1 | Innolux | 3.5 | 320×240 |
| TM027CDH19 | Tianma | 2.7 | 320×240 |
| TM035KDH03-79 | Tianma | 3.5 | 320×240 |
