| Varenummer | LW850AT9301 |
| Mærke | Innolux |
| Størrelse | 8.5 |
| Ansøgning | DPF |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 270 |
| CR | 300:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | CHIMEI INNOLUX |
| panel model | LW850AT9301 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.5 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 184.8×110.88 mm |
| omrids | 206.1×124.48×8.5 mm |
| overflade | Antiglare (Haze 25%) |
| lysstyrke | 270 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193150% |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | DPF |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| G085VW01 V0 | AUO | 8.5 | 800×480 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| G085VW01 V3 | AUO | 8.5 | 800×480 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG12 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG18 | SHARP | 8.5 | 800×480 |
| LQ085Y3DW01 | SHARP | 8.5 | 800×480 |
| LT085AC18N00 | TOSHIBA | 8.5 | 800×480 |
| LW850AT9301 | Innolux | 8.5 | 800×480 |
| A061VW01 V0 | AUO | 6.1 | 800×480 |
| A080SN01 V0 | AUO | 8.0 | 800×600 |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| CLAA104XA01CW | CPT | 10.4 | 1024×768 |
| EJ080NA-04C | Innolux | 8.0 | 1024×768 |
| HSD070ISN1-D00 | HannStar | 7.0 | 800×600 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| HSD101PFW2-B00 | HannStar | 10.1 | 1024×600 |
| LB104S02-TD01 | LG Display | 10.4 | 800×600 |
| PM070WM3 | E Ink | 7.0 | 800×480 |
