| Varenummer | HSD070ISN1-D00 |
| Mærke | HannStar |
| Størrelse | 7.0 |
| Ansøgning | DPF |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 600:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | HannStar |
| panel model | HSD070ISN1-D00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 141.6×106.2 mm |
| omrids | 156.4×122.25×4.4 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193150% |
| responstid | 2.4/5.6 (Typ.)(Tr/Td) |
| synsvinkel | 60/70/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2S5PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 60 pins |
| indgangsspænding | 3.3/9.5/16.5/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | DPF |
