| Varenummer | M070SW46 R0 |
| Mærke | IVO |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 1200×1920 |
| Sammensætning | LCM |
| Lysstyrke | 380 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | IVO |
| panel model | M070SW46 R0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.5×151.2 mm |
| omrids | 104×161.37×3.59 mm |
| overflade | Antiglare, Hard coating (3H), Antireflection |
| lysstyrke | 380 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 30 (Max.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | MIPI (4 data lanes), 31 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
