| Varenummer | M090AWA5 R0 |
| Mærke | IVO |
| Størrelse | 9.0 |
| Ansøgning | Outdoor High Brightn |
| Løsning | 1280×720 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 7S4P |
| Interface | |
| fabrikant | IVO |
| modelnavn | M090AWA5 R0 |
| skærmstørrelse | 9.0 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1280(RGB)×720 (WXGA) 163PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 198.72 × 111.78 (H×V) |
| omrids (mm) | 212.2 × 127.5 × 10.5 (H×V×D) |
| rammeareal (mm) | 201.72 × 114.78 (H×V) |
| behandling | Antiglare, Hard coating (3H), Reflection 6.0% (Max.) |
| luminans | 880 cd/m² (Typ.) |
| kontrastforhold | 1000 : 1 (Typ.) (TM) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| respons | 30 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | IPS, Normally Black, Transmissive |
| farvedybde | 16.7M 70% NTSC |
| baggrundsbelysning | 7S4P WLED , 15K hours , No Driver |
| masse | 335g (Max.) |
| anvendes til | Outdoor High Brightness Automotive Display |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
