| Varenummer | M116NWR1 R1 |
| Mærke | IVO |
| Størrelse | 11.6 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | IVO |
| panel model | M116NWR1 R1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 11.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 256.125×144 mm |
| omrids | 278×167×3.7 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | Antiglare |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| HN116WX1-100 | BOE | 11.6 | 1366×768 |
| LP116WH1-TLA1 | LG Display | 11.6 | 1366×768 |
| M116NWR1 R0 | IVO | 11.6 | 1366×768 |
| M116NWR1 R1 | IVO | 11.6 | 1366×768 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| M116NWR1 R7 | IVO | 11.6 | 1366×768 |
| M116NWR4 R0 | IVO | 11.6 | 1366×768 |
| M116NWR6 R0 | IVO | 11.6 | 1366×768 |
| N116BGE-L11 | Innolux | 11.6 | 1366×768 |
| N116HSE-EA1 | Innolux | 11.6 | 1920×1080 |
| B154EW01 V3 | AUO | 15.4 | 1280×800 |
| B156XW02 V2 HW4A | AUO | 15.6 | 1366×768 |
| BT140GW02 V.0 | Innolux | 14.0 | 1366×768 |
| LP133WH1-TLA2 | LG Display | 13.3 | 1366×768 |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP173WF2-TPB1 | LG Display | 17.3 | 1920×1080 |
| LTN140KT13-B01 | Samsung | 14.0 | 1600×900 |
| LTN154X3-L01 | Samsung | 15.4 | 1280×800 |
| NV125QUM-N81 | BOE | 12.5 | 3840×2160 |
| NV133FHM-N52 | BOE | 13.3 | 1920×1080 |
