| Varenummer | M201P1-L03 |
| Mærke | Innolux |
| Størrelse | 20.1 |
| Ansøgning | DMPC |
| Løsning | 1400×1050 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | M201P1-L03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.1 inch |
| løsning | 1400(RGB)×1050 , SXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 408.24×306.18 mm |
| omrids | 432×331.5 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 1.3/3.7 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM201WE3-TLF8 | LG Display | 20.1 | 1680×1050 |
| LQ201U1LW18 | SHARP | 20.1 | 1600×1200 |
| LTM201M1-L01 | Samsung | 20.1 | 1680×1050 |
| M201EW02 V0 | AUO | 20.1 | 1680×1050 |
| M201EW02 VG | AUO | 20.1 | 1680×1050 |
| M201P1-L01 | Innolux | 20.1 | 1400×1050 |
| M201P1-L03 | Innolux | 20.1 | 1400×1050 |
| M201UN04 V0 | AUO | 20.1 | 1600×1200 |
| NL256204AM15-02A | NLT | 20.1 | 2560×2048 |
| T201VN01 V1 | AUO | 20.1 | 640×480 |
| CLAA185WA03 | CPT | 18.5 | 1366×768 |
| CLAA220WA01 | CPT | 21.6 | 1680×1050 |
| IAWS64 | IDTech | 20.1 | 1680×1050 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| LTM315FL01 | Samsung | 31.5 | 3840×2160 |
| M185B1-L02 | Innolux | 18.5 | 1366×768 |
| M190PW01 V0 | AUO | 19.0 | 1440×900 |
| M236H1-L01 | Innolux | 23.6 | 1920×1080 |
| M240J1-L03 | Innolux | 24.0 | 1920×1200 |
| M270HW01 V1 | AUO | 27.0 | 1920×1080 |
