| Varenummer | M280HKJ-L30 |
| Mærke | Innolux |
| Størrelse | 28.0 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | M280HKJ-L30 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 28.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 620.928×341.28 mm |
| omrids | 649.3×369.6×15.3 mm |
| overflade | Antiglare (Haze 3.4%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 6.5 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 stringsWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
