| Varenummer | N101ICE-G62 |
| Mærke | Innolux |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | INNOLUX |
| panel model | N101ICE-G62 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | AAS, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| omrids | 228.6×149.2×4.6 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 stringsWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| HSD101PFW4-B01 | HannStar | 10.1 | 1024×600 |
| LTN101NT05-U03 | Samsung | 10.1 | 1024×600 |
| N101ICE-G62 | Innolux | 10.1 | 1280×800 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.A1 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.B1 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
| N101ICG-L21 Rev.C2 | Innolux | 10.1 | 1280×800 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| HX121WX1-111 | HYDIS | 12.1 | 1280×800 |
| LP094WX1-SLA1 | LG Display | 9.4 | 1280×800 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LQ101R1SX03 | SHARP | 10.1 | 2560×1600 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N101ICG-L21 Rev.C1 | Innolux | 10.1 | 1280×800 |
