| Varenummer | LP097QX1-SPC1 |
| Mærke | LG Display |
| Størrelse | 9.7 |
| Ansøgning | PAD |
| Løsning | 2048×1536 |
| Sammensætning | LCM |
| Lysstyrke | 440 |
| CR | 600:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LP097QX1-SPC1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.7 inch |
| løsning | 2048(RGB)×1536 , QXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 196.608×147.456 mm |
| omrids | 208.88×167.12 mm |
| overflade | Glare (Haze 0%), Hard coating (3H), Antireflection |
| lysstyrke | 440 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | eDP (4 Lanes), 51 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPA2 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC2 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPC3 | LG Display | 9.7 | 2048×1536 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| HV121WX5-111 | HYDIS | 12.1 | 1280×800 |
| LP097X02-SLA2 | LG Display | 9.7 | 1024×768 |
| LTL106HL02-001 | Samsung | 10.6 | 1920×1080 |
| LTN070NL01 | Samsung | 7.0 | 1024×600 |
| LTN097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| LTN097XL01-A02 | Samsung | 9.7 | 1024×768 |
| TFTMD070021 | JDI | 7.0 | 1200×1920 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
