| Varenummer | NE156QUM-N61 |
| Mærke | BOE |
| Størrelse | 15.6 |
| Ansøgning | Laptop |
| Løsning | 3840×2160 |
| Sammensætning | LCM, Oxide TFT-LCD |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 8S8P |
| Interface | eDP |
| fabrikant | BOE |
| modelnavn | NE156QUM-N61 (BOE0732) |
| skærmstørrelse | 15.6 inch |
| skærmtype | LCM, Oxide TFT-LCD |
| pixel antal | 3840(RGB)×2160 (UHD) 283PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 344.218 × 193.622 (H×V) |
| omrids (mm) | 350.66 × 216.25 × 2.6 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare |
| luminans | 350 cd/m² (Typ.) |
| kontrastforhold | 1000 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 25 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | ADS, Normally Black, Transmissive |
| farvedybde | 16.7M 72% NTSC |
| baggrundsbelysning | 8S8P WLED , 15K hours , With LED Driver |
| konturform | Slim (PCBA Flat, T≤3.2mm) |
| anvendes til | Laptop |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | eDP (4 Lanes) , eDP1.4a , HBR2 (5.4G/lane) , Connector 40 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
