| Varenummer | NL204153AC21-09 |
| Mærke | NLT |
| Størrelse | 21.3 |
| Ansøgning | MD |
| Løsning | 2048×1536 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 750:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | NEC |
| panel model | NL204153AC21-09 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.3 inch |
| løsning | 2048(RGB)×1536 , QXGA |
| visningstilstand | UA-SFT, Normally Black, Transmissive |
| aktivt område | 433.152×324.864 mm |
| omrids | 457×350×37 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 750:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 14/10 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 16 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (4 ch, 8-bit), 80 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
| ITQX21G | IDTech | 20.8 | 2048×1536 |
| ITQX21K | IDTech | 20.8 | 2048×1536 |
| ITSX88E | IDTech | 18.1 | 1280×1024 |
| LB190E01-SL01 | LG Display | 19.0 | 1280×1024 |
| NL160120AC27-37 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07A | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R190EFE-L61 | Innolux | 19.0 | 1280×1024 |
| R208R3-L01 | Innolux | 20.8 | 2048×1536 |
