| Varenummer | NL160120AC27-37 |
| Mærke | NLT |
| Størrelse | 21.3 |
| Ansøgning | MD |
| Løsning | 1600×1200 |
| Sammensætning | LCM |
| Lysstyrke | 900 |
| CR | 1400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | NLT |
| panel model | NL160120AC27-37 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.3 inch |
| løsning | 1600(RGB)×1200 , UXGA |
| visningstilstand | SFT, Normally Black, Transmissive |
| aktivt område | 432×324 mm |
| omrids | 457×350×22 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 900 cd/m² (Typ.) |
| kontrastforhold | 1400:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| NL160120AC27-32B | NLT | 21.3 | 1600×1200 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL204153BM21-04A | NLT | 21.3 | 2048×1536 |
| R190E5-L01 | Innolux | 19.0 | 1280×1024 |
| R190E6-L01 | Innolux | 19.0 | 1280×1024 |
| R190EFE-L61 | Innolux | 19.0 | 1280×1024 |
| R208R3-L01 | Innolux | 20.8 | 2048×1536 |
| R213T3-L01 | Innolux | 21.3 | 2560×2048 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
