| Varenummer | B116HAN03.1 |
| Mærke | AUO |
| Størrelse | 11.6 |
| Ansøgning | PAD |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | AUO |
| panel model | B116HAN03.1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 11.6 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 256.32×144.18 mm |
| omrids | 270.37×159.79×4.9 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193152% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
