| Varenummer | PA079DS4 |
| Mærke | E Ink |
| Størrelse | 7.9 |
| Ansøgning | DPF |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 350:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PA079DS4 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.9 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 161.28×117.936 mm |
| omrids | 191.4×144.6 mm |
| overflade | Antiglare, Hard coating |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | Full color |
| responstid | 30/50 (Max.)(Tr/Td) |
| synsvinkel | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 20 pins |
| indgangsspænding | 5/5/17/-15V (Typ.)(VCC/VDD/VGH/VGL) |
| Ansøgning | DPF |
