| Varenummer | CLAA062LA01CW |
| Mærke | CPT |
| Størrelse | 6.2 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 600:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | CPT |
| panel model | CLAA062LA01CW |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.2 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 137.52×77.323 mm |
| omrids | 155.2×88.2×5.3 mm |
| overflade | Antiglare |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193150% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 75/75/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S6PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 60 pins |
| indgangsspænding | 3.3/9.2/18/-6.0/-4.0V (Typ.)(DVDD/AVDD/VDDG/VEEG/VCOM) |
| Ansøgning | CNS |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA061LA0DCW | CPT | 6.1 | 800×480 |
| CLAA062LA01CW | CPT | 6.2 | 800×480 |
| CLAA069JA11CW | CPT | 7.0 | 480×234 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| AV080WSM-NW0 | BOE | 8.0 | 1024×600 |
| C058GW01 V0 | AUO | 5.8 | 400×240 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| L5F30369P01 | SANYO | 6.5 | 800×480 |
| LQ070T5DR06 | SHARP | 7.0 | 480×240 |
| LTE052T-45 | Philips | 5.0 | 320×234 |
| M090SWP1 R0 | IVO | 9.0 | 800×480 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| PW070NS1W2 | E Ink | 7.0 | 480×320 |
| TD070WGCB2 | TPO | 7.0 | 854×480 |
