| Varenummer | R190E5-L01 |
| Mærke | Innolux |
| Størrelse | 19.0 |
| Ansøgning | MD |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 1300 |
| CR | 1000:1 |
| Farver | Grayscale |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | R190E5-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1280(LCR)×1024 , SXGA |
| visningstilstand | DD-IPS, Normally Black, Transmissive |
| aktivt område | 376.32×301.056 mm |
| omrids | 396×324×37 mm |
| overflade | Antiglare |
| lysstyrke | 1300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | Grayscale (8-bit) |
| responstid | 15/5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 14 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
