| Varenummer | G213QAN01.0 |
| Mærke | AUO |
| Størrelse | 21.3 |
| Ansøgning | MD |
| Løsning | 2048×1536 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 1400:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | G213QAN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.3 inch |
| løsning | 2048(RGB)×1536 , QXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 433.152×324.864 mm |
| omrids | 457×350×22.8 mm |
| overflade | Antiglare |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 1400:1 (Typ.) |
| vise farver | 1.07B (10-bit), CIE193174% |
| responstid | 13/12 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (4 ch, 8-bit), 82 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
| G213QAN01.0 | AUO | 21.3 | 2048×1536 |
| LTM213U4-L01 | Samsung | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL204153AC21-09 | NLT | 21.3 | 2048×1536 |
| NL204153AC21-22 | NLT | 21.3 | 2048×1536 |
| NL204153BM21-04A | NLT | 21.3 | 2048×1536 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| TX54D11VC0CAB | JDI | 21.3 | 1600×1200 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
| IAUX61 | IDTech | 19.6 | 1600×1200 |
| LQ201U1LW11Z | SHARP | 20.1 | 1600×1200 |
| NL160120BM27-03A | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07A | NLT | 21.3 | 1600×1200 |
| NL204153BM21-01A | NLT | 21.3 | 2048×1536 |
| R190E5-L01 | Innolux | 19.0 | 1280×1024 |
| R190E6-L01 | Innolux | 19.0 | 1280×1024 |
| R196U2-L01 | Innolux | 19.6 | 1600×1200 |
| R300SFE-L02 | Innolux | 30.0 | 3280×2048 |
| VVX28T143H00 | Panasonic | 28.0 |
