| Varenummer | TD024THEB2 |
| Mærke | TPO |
| Størrelse | 2.4 |
| Ansøgning | DSC |
| Løsning | 480×240 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | TPO |
| panel model | TD024THEB2 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 480×240 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 48.05×35.76 mm |
| omrids | 55.2×47.5 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | |
| synsvinkel | 40/40/20/50 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsWLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, 40 pins |
| indgangsspænding | 3.0V (Typ.) |
| rohs: | |
| Ansøgning | DSC |
