| Varenummer | AM-240320-024DT |
| Mærke | Other |
| Størrelse | 2.4 |
| Ansøgning | HHP |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | Amson |
| panel model | AM-240320-024DT |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.4 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 36.72×48.96 mm |
| omrids | 42.72×60.26×3.8 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K |
| responstid | |
| synsvinkel | |
| lampe type | 4 stringsWLEDWithout Driver |
| signal interface | 8/16-bit 8080 parallel, 40 pins |
| indgangsspænding | 2.8/2.8V (Typ.)(IOVCC/VCI) |
| Ansøgning | HHP |
