| Varenummer | TFT240320-237-E |
| Mærke | Other |
| Størrelse | 2.8 |
| Ansøgning | MPH |
| Løsning | 240×320 |
| Sammensætning | LCM |
| Lysstyrke | 125 |
| CR | 95:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU/RGB/SPI |
| panel mærke | TRULY |
| panel model | TFT240320-237-E |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.8 inch |
| løsning | 240(RGB)×320 , QVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 43.2×57.6 mm |
| omrids | 50×69.2 mm |
| overflade | |
| lysstyrke | 125 cd/m² (Typ.) |
| kontrastforhold | 95:1 (Typ.)(Transmissive)3.5:1 (Typ.)(Reflective) |
| vise farver | 262K |
| responstid | 32.8 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/41/32 (Typ.)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S4PWLEDWithout Driver |
| signal interface | CPU/RGB/SPI, 47 pins |
| indgangsspænding | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
| C0240QGLG-T | CMEL | 2.4 | 240×320 |
| DX08D11VM0AAA | KOE | 3.0 | 480×800 |
| HSD015F4N2-B | HannStar | 1.5 | 128×128 |
| LH550WF2-SD01 | LG Display | 5.5 | 1080×1920 |
| LQ043Y1DX01 | SHARP | 4.3 | 480×800 |
| LS055R1SX03 | SHARP | 5.5 | 1440×2560 |
| LS063K3SX54 | SHARP | 6.3 | 720×1280 |
| TM018FDZ12 | Tianma | 1.8 | 128×160 |
| TM022HDH31 | Tianma | 2.2 | 240×320 |
| TM032PDZ04 | Tianma | 3.2 | 320×480 |
