| Varenummer | DX08D11VM0AAA |
| Mærke | KOE |
| Størrelse | 3.0 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 400:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | HITACHI |
| panel model | DX08D11VM0AAA |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.0 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 38.88×64.8 mm |
| omrids | 45.6×76.4 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193171% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1S6PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6/8-bit) + SPI, 49 pins |
| indgangsspænding | 1.8/2.8/2.8V (Typ.)(IOVCC/VCC/VCI) |
| Ansøgning | MPH |
